LSZH Single Mode Self Supporting 1 4 2 Core FTTH Drop Cable

  • 1
  • 2

Brand Name : KNOFC

Model Number : GJYXCH 1 Core

Certification : CE/ISO9001

Place of Origin : China

MOQ : 10km

Price : Negotiable

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 2000000M/Week

Delivery Time : 8-10 working days

Packaging Details : Wooden reel with box

Fiber count : 1, 2, 4 core

Fiber type : G657A2

Strengthened Messenger Wire : Galvanized steel wire

Outer sheath material : LSZH - Low smoke zero halogen

Packaging : Wooden reel with box

Application : FTTH

Life expectancy : more than 30 years

Operating Temperature : -40°C to+70°C

Contact Now

FTTH Drop Cable 1 2 4 Core Single Mode Self-supporting LSZH Sheath



Description:

FTTH Drop Cable directly connected to their homes, their bandwidth, wavelength and transmission technology type are not restricted. The optical fiber unit id positioned in the centre. Two parallel strength member are placed at the two sides. A steel wire as the additional strength member is also applied ,then, the cable is completed with a black LSZH sheath.



Characteristics:

1. Special low-bend-sensitivity fiber provides high bandwidth and excellent communication transmission property;

2. Simple structure, light weight and high practicability;

3. Low smoke, zero halogen and flame retardant sheath.



Application:

1. Adopted to outdoor distribution;

2. Suitable for aerial, pipeline laying method;

3. As FTTH cable,for outdoor horizontal and vertical cabling.



Technical Data:

 Item  Contents  Value
 Central strength member  Material  FRP / KFRP / steel wire
 Central strength member  Diameter  0.5mm*2+1.0mm
 Outer sheath  Material  LSZH
 Outer sheath  Thickness  0.5mm~0.8mm



Cable Mechanical characteristic:

  Cable type   Diameter(mm)   Weight
 (kg/km)		   Tensile strength
  Long/short term
         (N)		   Bending radius
  Dynamic/static
         (mm)		  Storage temperature
          ( ℃ )
 GJYXCH-1~2          2.0*5.0      22          300/600         20D/10D             -20~+70
 GJYXCH-2~4          2.0*5.0      19          300/600         20D/10D             -20~+70
